Vacuum Glazing Tips


Vacuum glazing is a revolutionary new form of double-glazing. It utilizes an internal vacuum seal between its two glass sheets to minimize space-heating energy loss and increase insulation properties. An exceptionally fantastic fact about Tempered vacuum glazing.

The design and manufacturing of vacuum-insulated glazing present numerous challenges. These include hermetically sealing the edges of glass sheets to prevent gaseous thermal conduction and maintaining an effective vacuum for extended periods.

1. Clean the Glass

To keep your vacuum glazing looking its best, it is wise to occasionally wipe down with a wet wipe to remove dirt, overspray, or any other build-up from its surfaces. Doing this will allow for easier maintenance.

To simplify this task, I suggest drilling some holes into the frame of your window to place a desiccate packet and rinse your glass surface with isopropyl (rubbing alcohol).

Vacuum-insulated glazing is an ideal option for passive house builds and can help lower heating bills significantly. In addition, it boasts superior energy efficiency with a lower U-value than double or triple-glazed units.

Double and triple-glazed units may offer superior soundproofing performance regarding traffic noise. In contrast, single-glazing teams tend to be more energy efficient and reduce your carbon footprint.

2. Fill the Pillars

Vacuum glazing fabrication requires hermetically sealing glass pane edges together using an edge seal (usually low melting point glass frit) at temperatures over 500 deg C to bar them from leakage and air infiltration.

Small cylindrical metal support pillars were introduced into vacuum double-glazing units to offset the vacuum pressure to serve as counterpoints. These support structures were strategically distributed throughout the vacuum space and were nearly invisible to the naked eye – maintaining separation between sheets of glass while keeping their break.

Pillars can be made of various materials and may include multiple layers and coatings with a binder, compliant layer, adhesive layer, and orientation layers. Furthermore, thermal stability, radiation, or photoinitiator layers may also be included as optional components of these pillars.

3. Fill the Space Between the Pillars

Practical designs of vacuum glazing require that pillars be constructed of material with extremely high compressive strength to avoid deforming under shear forces when glass bends over them.

Un pillars not constructed from solid material may be subject to significant shear stresses that cause localized fractures. Furthermore, soft contact layers on each end may deform more readily under shear than their cores do, necessitating careful spacing of pillars to preserve vacuum gaps and prevent shear cracking.

Vacuum-insulated glass offers numerous advantages over single-pane glass and is particularly suited to conservation areas or listed buildings. Its thickness is one-third that of traditional double-glazing units while providing four times more insulation. Furthermore, vacuum-insulated glass units tend to be quieter, which helps lower noise levels in homes.

4. Seal the Space Between the Pillars

Vacuum insulated glass (VIG) is an insulating glazing comprising two sheets of hermetically sealed glass around their edges to form an airtight, thermally insulating vacuum chamber. Due to atmospheric pressure forces, support pillars are placed between them to keep them apart.

To prevent vacuum-induced cracking or breakage of pillars, they must be constructed from materials with very high compressive strength. Furthermore, their dimensions must be relatively thin, such as between 0.1 to 0.2 mm in height and 0.2 to 0.3 mm in diameter.

These pillars must be covered with soft layers made of metals or carbon. Furthermore, their soft layers should form an integral interface between their central body and adjacent glass surfaces at either end.
